Thermostat Microscope TH20W

Model: TH20W

1. Homothermal range:Room temperature -50℃
2. Total Magnification:40-640X
3. Eyepiece:WF10X/16mm, H16X/10.5mm
4. Objective:4X, 10X, 40X
5. Viewing Head:45° inclined, 360° rotatable
6. Nosepiece:Three holes inward
7. Focusing mechanism:Different coarse and fine focusing knob, coarse focusing range 12mm, fine focusing graduation: 1.3mm
8. Illumination: LED cold light source, high brightness, adjustable brightness
9. Condenser: Wool glass, single lens
10. Camera interface: No

Quantity:
Availability:





Inquire Add to Basket

Model:
TH20W
Brand:
TOP

Characteristic:

Curved arm handle

Built-in handle, easy to take and move

Thermostat stage

The heating stage is made of specially formed aluminum alloy, and the temperature rise is uniform and stable.

The working surface temperature adopts LED digital display, accurate reading, temperature control range: room temperature -50℃

Fast and uniform heating, easy operation and safe use

Lighting system

Plano-concave mirror, 40mm (optional)

High-brightness LED, cold light source, rechargeable, adjustable brightness(standard)

Related Products

content is empty!

Viewing tube	Monocular, 45° inclined, 360° rotatable
Eyepiece	WF10X/16mm, H16X/10.5mm
Objective	Achromatic objective 4X
	Achromatic objective 10X
	Achromatic objective 40X (Spring)
Nosepiece	Three holes inward
Homothermal stage
Homothermal range	Room temperature -50℃
Control accuracy	≤±1℃
Heating power	12V
Power	36W
Focusing system	Different coarse and fine focusing knob, coarse focusing range 12mm, fine focusing graduation: 1.3mm
Condenser	Wool glass, single lens
Illumination	LED cold light source, high brightness, adjustable brightness
Power supply	12V/4A switching power adapter
Package	Foam+Carton

Viewing tube	Monocular, 45° inclined, 360° rotatable
Eyepiece	WF10X/16mm, H16X/10.5mm
Objective	Achromatic objective 4X
	Achromatic objective 10X
	Achromatic objective 40X (Spring)
Nosepiece	Three holes inward
Homothermal stage
Homothermal range	Room temperature -50℃
Control accuracy	≤±1℃
Heating power	12V
Power	36W
Focusing system	Different coarse and fine focusing knob, coarse focusing range 12mm, fine focusing graduation: 1.3mm
Condenser	Wool glass, single lens
Illumination	LED cold light source, high brightness, adjustable brightness
Power supply	12V/4A switching power adapter
Package	Foam+Carton
